VL LRS55 Pole Scabblers & Tampers*
The VL LRS55 is a powerful long-reach scabbler designed for vertically preparing hard-to-reach areas. It efficiently removes concrete while preserving the integrity of the underlying substrate. Equipped with the Vibro-Lo™ low vibration system as standard, the VL LRS55 helps minimise the risk of vibration-related injuries, ensuring a safer working environment for operators.
* All Pole Scabblers are easily converted into Tampers by changing the head attachment over. Our range of scabbler heads and tamper feet can be found in the consumables section below.
Low vibration options available
Applications
- Heavy scabbling of hard to access areas such as below re-inforcement bars and between shuttering.
- Scabbling of corners, edges and joints.
- Fast removal of material.
- Aggressive keying without damaging the substrate.
Features
- Easy to change cutter heads minimise downtime.
- Angled air inlet to direct hose away from operator.
- Hand guard to protect operator.
- At 1.4 metres in length it allows scabbling into inaccessible areas.
- Compactor foot attachment available for increased functionality.
- 9 point head option available for profiling.
Key specifications
VL LRS55 c/w 5 Point Scabbler Head
150.5320
| Part Number | 150.5320 |
| Weight (kg) | 21.5 |
| Length (mm) | 1270 |
| Blows Per Min (BPM) | 1300 |
| Air Consumption (lps – cfm) | 11.6 – 24.6 |
| Air Pressure | 6.2 bar (90 psi) |
| Air Inlet | (1/2″ BSP Air Inlet) |
| Vibration level (Aeq m/s2) Primary | 4.2m/s² (K= -0% + 40%) |
| Vibration level (Aeq m/s2) Secondary | 3.9m/s² (K= -0% +40%) |
| Sound Pressure Level | 98 |
VL LRS55 c/w 9 Point Scabbler Head
150.5321
| Part Number | 150.5321 |
| Weight (kg) | 21.5 |
| Length (mm) | 1270 |
| Blows Per Min (BPM) | 1300 |
| Air Consumption (lps – cfm) | 11.6 – 24.6 |
| Air Pressure | 6.2 bar (90 psi) |
| Air Inlet | (1/2″ BSP Air Inlet) |
| Vibration level (Aeq m/s2) Primary | 4.2m/s² (K= -0% + 40%) |
| Vibration level (Aeq m/s2) Secondary | 3.9m/s² (K= -0% +40%) |
| Sound Pressure Level | 98.0 |
Consumables
Scabbler Head 5 Point Bush
Part no. 441.5359
Scabbler Head 9 Point Bush
Part no. 441.5369
Scabbler Head Cruciform
Part no. 441.5360
Round Compactor Foot
Part no. 450.5017
Square Compactor Foot
Part no. 450.5011
Compactor Foot
152 x 127 mm
Part no. 450.5013
Compactor Foot
100 X 200 mm
Part no. 450.5016
View moreView less
Accessories
VL LRS55 Pole Scabbler Service Kit
Part no. 446.5005
VL LRS55 Pole Tamper Service Kit
Part no. 446.5000
Whip Hose & Oiler Assembly
Part no. 458.1580
¾’’ BSP Inline Lubricator
Part no. 859.1580
¾’’ Air Hose Complete with couplings
15m length
Part no. 843.0752
Whip Check
Part no. 815.5550
ISSA: 55.091.73
View moreView less
